I-180TS2
Apron Cylinder I-180TS2 Part No. A125065
Key Number Part Number Description
1 A125065-1a O-RING (-248)
2 A125065-1b B/U RING 5” OD X 1-8” C.S. (-248)
3 A125065-2 ROD SEAL U-CUP
4 AHS-00096 WIPER SEAL
5 A125065-4 WEAR RING
6 A123324-9 PISTON SEAL = PSP TYPE
7 A125065-6 WEAR RING
8 A125065-01 BARREL
9 A125065-02 HEAD
10 AFN-00018 LOCK NUT
11 A125065-04 ROD
12 A125065-03 PISTON
13 A123322-09 Pin: Apron cylinder barrel end
A125065-05 "SEAL KIT, INCLUDES ITEMS 1 - 7"
