PARTS LIST
HYDRAULIC CIRCUIT
s/n 16510 & up
KEY # # REQ’D PART # DESCRIPTION
1 9 Elbow, 90°, 1/2" NPT, Cast
1A 2 Elbow, 90°, 1/2" NPT, Steel
2 2 Pipe, 1/2" x 41" long
3 6 A45H07 Swivel adapter, 90°, 3/8" male x 1/2" female
4 2 Pipe, 1/2" x 32-3/4" long
5 2 Pipe, 1/2" x 34-3/4" long
6 3 Pipe tee, 1/2" NPT, Cast
6A 4 Pipe tee, 1/2" NPT, Steel
7 3 A60H01A Hose, 1/2" x 18" long
8 5 A45H06 Hose, 1/2" x 24" long
9 2 Hose, 1/2" x 64" long
10 4 A101H74 Swivel adapter, straight, 1/2" female x female
11 2 A80H11 Hose, 1/2" x 40" long
12 1 Street elbow, 90°, 1/2" NPT, Cast
12A 4 A101H73 Street elbow, 90°, 1/2" NPT, Steel
13 1 A101H48 Counterbalance valve
14 1 A80H46 Hose, 1/2" x 51" long
15 1 Pipe, 1/2" x 25" long
16 1 A400H01 Hose, 1/2" x 38" long
17 1 Pipe, 1/2" x 85-3/4" long
18 1 Pipe, 1/2" x 47-1/4" long
19 5 A400H02 Swivel adapter, 90°, 1/2" male x female
20 2 A80H29 Hose, 1/2" x 46" long
21 1 Pipe, 1/2" x 39-3/4" long
22 1 Pipe, 1/2" x 37-1/4" long
23 2 Pipe bushing, 3/4" NPT x 1/2" NPT
24 2 Street elbow, 45°, 1/2" NPT, Cast
25 1 Pipe, 1/2" x 3" long
26 1 Pipe, 1/2" x 13" long
27 1 A600H28 Check valve
