Ashland 80S - Manual (Page 2)

Page 3. Operator and Maintenance Instructions
Page 4. Safety Guidelines
Page 5. Illustration - Assembly
Page 6-7. Assembly Instructions
Page 8. Frame Assembly
Page 9. Linkage Cylinder
Page 10. Pole and Axle Assembly
Page 11. Actuating Assembly
Page 12. Bucket and Apron Assembly
Page 13. Wheel, Hub and Spindle Assembly
Page 14. Hydraulic Cylinder (5” x 20”)
Page 15. How to Operate the W7B-20DC Rim
Page 16. Warranty Statement
HOW TO ORDER PARTS:
IMPORTANT
Parts must be ordered through your local authorized ASHLAND dealer.
Be sure to state MODEL and SERIAL NUMBER of your machine, PART NUMBER, DESCRIPTION
and QUANTITY needed.
Unless this is done, we cannot provide prompt service or assure shipment of the correct parts.
2
INDEX
Model 80 Scraper
Ashland Industries weldable replacement parts are availabe to rebuild, modify or
update your scraper to current factory specifications.
