1 13 3
© 2004 Directed Electronics, Inc.
its memory and will continue to chirp four or five times each time
the system is disarmed, until the next time the ignition is turned on.
A zone is represented by the number of LED flashes used by the
system to identify a particular type of input. Standard input assign-
ments are listed in the following table, along with spaces to write
in any optional sensors or switches that you have had installed.
ZZO ON NEE
(Number of D DEEA ALLEER R--IIN NSSTTA ALLLLEED D
LED Flashes)
D DEESSCCR RIIP PTTIIO ON N O OP PTTIIO ON NSS
1 1 Instant trigger for optional sensor,
hood or trunk pins
2 2
A heavier impact detected by
the on-board impact sensor
3 3
Door switch trigger
5 5
Ignition trigger
N NO OTTEE:: The LED does not report when the warn-away response has been
activated; it only reports triggered sequences.
TTaab bllee o off ZZo on neess
