Page 19
Split Conveyor
KEY
PART NO.
PART NAME
QTY
REMARKS
1
1550270
Washer, flat
2
SAE 1"
2
N/A
Bushing
2
Nylon 2-1/4" OD x 1"
3
N/A
Sprocket, idle - top
2
6T 1-7/16" bore
6008083
Sprocket w/bushing
2
1-1/8"
4
6008085
Shaft, Idle - top
1
1" x 18-1/2"
5
N/A
Nut, flange
2
1/2-13 NC
6
6008086
Spring, compression
2
1" Dia. X 5"
7
6008080
Bracket
??
8
6008087
Bolt, adjustment
4
1/2-13 nc x 12
9
N/A
Nut, hex
??
SIZE?
10
N/A
Washer, flat
??
SIZE?
11
N/A
Bearing, 2 bolt flange
2
1" bore
12
N/A
Sprocket, drive
2
6T 1" bore
13
1550181
Pin
2
3/8" x 2" sprial HBK
14
6008090
Shaft, drive - top
1
1" x 20"
15
1540898
Motor, hydraulic
ref
101-1019
1541780
Motor, hydraulic
ref
101-1751
16
6008011
Mount, hydraulic motor
1
17
6008084
Conveyor complete - split
1
6008076
Conveyor body (weldment)
ref
18
N/A
Capscrew, hex
4
SIZE?
19
1550108
Nut, hex
4
1/2-13 NC
20
N/A
n/a
21
N/A
n/a
22
N/A
n/a
23
6008078
Chain, split conveyor - short
1
(CA550, #PITCHES & SLATS)
24
6008077
Chain, split conveyor - long
1
(CA550, #PITCHES & SLATS)
25
N/A
Washer, flat
4
SAE 1/2"
26
N/A
Capscrew, hex
4
1/2-13 NC X LENGTH?
27
N/A
Bracket, adjusting end mount
2
28
1520773
Sprocket, idle
4
6T 1-1/4" bore
29
6008089
Guard, conveyor chain - split
1
30
N/A
Washer, flat
4
SIZE?
31
N/A
Pin
4
SIZE?
32
6008081
Shaft, conveyor intermediate
1
1-1/4" x 34-1/2"
33
N/A
Capscrew, hex
4
SIZE?
34
N/A
Nut, flange
8
SIZE?
35
6008079
Conveyor end, adjusting
1
36
N/A
Nut, hex
4
SIZE?
37
6008088
Bearing, 2 bolt flange
2
1-1/4" bore
38
6008075
Door assembly, conveyor w/hooks
1
Ag-Bag Int'l
6/18/02
G6070
