PAGE 9
G6000 PARTS SECTION
00.06.08
CABLE DRUM
Item# Part# DESCRIPTION Qty. Remarks
1 1590002 Wire Rope, Cable Rewind 2 7/16” x 185’
2 6003029 Cable Drum Assembly 8-9’ 1
2a 6003021 Coupler, Cable Drum Weld 1
2b 6003024 Cable Drum, Non Brake Side 8-9’ 1
2c 6003025 Cable Drum, Brake Side 8-9’ 1
3 1030017 Crank, Cable Rewind 1
4 6003014 Shoe, Cable Rewind-Right 1 1”
5 1510044 Bearing 2 2” 4-Bolt Flange 5-1/8”BP
6 6003013 Shoe, Cable Rewind-Left 1 1”
7 1510047 Bearing 2 2” Split Babbit
7a Ref. Bearing, Split Base Ref.
7b Ref. Bearing, Split Top Ref.
7c Ref. Capscrew, Bearing Connector Ref.
7d 1541637 Fitting, Grease 2 1629-B 1/4” 67-1/2” Deg.
8 1030069 Shaft, Cable Rewind 2 1” x 24-1/8”
9 1550081 Capscrew, Hex Head 4 5/8”-11 NC x 2-1/4” G5
10 1550148 Nut, Hex 4 5/8”-11 NC Nyloc
11 1550126 Nut, Hex 8 1/2”-13 NC Lock
12 1550018 Capscrew, Hex Head 8 1/2”-13 NC x 1-1/4” G5
13 1550325 Capscrew, Hex Head 1 3/8”-16 NC x 2-3/4”
14 1550147 Nut, Hex 1 3/8”-16 NC Nyloc
15 1550326 Pin, Hair 2 1/8”
REPLACE WITH PIN
PIN 1550161
