Page 13: Pm-12
STRETCHER ARM HYDRAULIC GROUP
MR5603
KEY
PART NO.
PART NAME
QTY
REMARKS
1
1540659
FITTING, HYDRAULIC COUPLER
4
C5405 X 8 X 8
2
1540101
CYLINDER, HYDRAULIC
2
DB316
3
5600113
HARDLINE ASSEMBLY - RIGHT
1
1541068
TUBING, HYDRAULIC
1
1/2
1540217
NUT
2
FC-2875 X 8
1540224
SLEEVE
2
FF-9605 X 8
4
1540710
FITTING, HYDRAULIC COUPLER
4
C5605 X 6
5
1541085
VALVE, BALL
5
1/4
6
1540384
FITTING, HYDRAULIC COUPLER
5
C3069 X 8 X 4
7
1540102
CYLINDER, HYDRAULIC
3
DB324 1-1/2 SHAFT
8
5600123
HARDLINE ASSEMBLY - TOP
3
1541068
TUBING, HYDRAULIC
1
1/2
1540217
NUT
2
FC-2875 X 8
1540224
SLEEVE
2
FF-9605 X 8
9
1541251
CLAMP, HYDRAULIC TUBE
5
1/2 SINGLE T
10
1100027
HOSE ASSEMBLY
2
42506U-606606-03000
11
1100028
HOSE ASSEMBLY
1
42506U-606606-03600
12
1540712
FITTING, HYDRAULIC COUPLER
1
C5605 X 8 X 8 X 8
13
1100030
HOSE ASSEMBLY
1
42506U-668608-01150
14
1100031
HOSE ASSEMBLY
1
42506U-608608-03500
15
1541074
VALVE, 2 BANK W/SOLENOID
1
V20
16
1540348
FITTING, HYDRAULIC COUPLER
1
7237 X 12
17
1500144
GAUGE, HYDRAULIC PRESSURE
1
3000 PSI BACK MOUNT
18
1540448
FITTING, HYDRAULIC COUPLER
1
C3359 X 4
19
1540701
FITTING, HYDRAULIC COUPLER
2
C5515 X 8 X 10
20
1540349
FITTING, HYDRAULIC
1
7237 X 14
21
1540680
FITTING, HYDRAULIC COUPLER
1
C5505 X 8
22
1100032
HOSE ASSEMBLY
1
42506U-686606-03900
23
1540710
FITTING, HYDRAULIC COUPLER
3
C5605 X 6
24
1100033
HOSE ASSEMBLY
2
42506U-608608-03000
25
1100034
HOSE ASSEMBLY
1
42506U-608608-03500
26
1540680
FITTING, HYDRAULIC COUPLER
1
C5505 X 8
27
1540651
FITTING, HYDRAULIC COUPLER
1
C5405 X 6
28
1100035
HOSE ASSEMBLY
1
42506U-606686-03600
29
5600115
HARDLINE ASSEMBLY, LEFT
1
1541068
TUBING, HYDRAULIC
1
1/2
1540217
NUT
2
FC-2875 X 8
1540224
SLEEVE
2
FF-9605 X 8
PM-12
