BALE RAM GROUP MR5603
KEY PART NO. PART NAME QTY REMARKS
1 1550018 CAP SCREW, HEX HEAD 10 1/2-13 NC X 1-1/4 G5
2 1150171 PIN, HITCH 1 5/8 X 4-3/4
3 5600106 TUBE ASSEMBLY, BALE RAM PIVOT/SOCKET 1
4 5600107 TUBE, BALE RAM EXTENSION 1
5 1550059 CAP SCREW, HEX HEAD 8 3/8-16 NC X 1-1/4 G5
6 1550317 BOLT, CARRIAGE 4 1/2-13 NC X 1-1/2
7 5600108 BALE PAN ASSEMBLY 1
8 1541159 MOTOR, HYDRAULIC 2 RE3208040 WHITE
9 1510056 BEARING 2 1-3/4 CAM FOLLOWER
10 1550144 NUT, HEX 4 1/2-13 NC NYLOC JAM
11 5600054 MOUNT ASSEMBLY, BALE RAM CHAIN-RIGHT 1
12 2113004 ALL THREAD 2 3/4 NC X 7"
13 5600111 PLATE ASSEMBLY, CHAIN HOUSING-RIGHT 1
14 1520076 LINK, ROLLER CHAIN CONNECTING 4 80 RC
15 1550125 NUT, HEX 4 5/8-11 NC
16 1520366 CHAIN, ROLLER 2 80 RC X 91 PITCH
17 1510077 BEARING 4 1-1/4 TAKE-UP
18 1520245 SPROCKET 2 80BS13 1-1/4 BORE 5/16 KW SS
19 2109011 KEYSTOCK 1 5/16 X 5/16 X 12 CR1018
20 5600054 MOUNT ASSEMBLY, BALE RAM CHAIN-LEFT 1
21 5600112 PLATE ASSEMBLY, CHAIN HOUSING LEFT 1
22 1550145 NUT, HEX 16 1/2-13 NC NYLOC
23 1550020 CAP SCREW, HEX HEAD 8 1/2-13 NC X 2 G5
24 1550021 CAP SCREW, HEX HEAD 8 1/2-13 NC X 2-1/2 G5
25 1550307 NUT, HEX 4 3/4-10 NC NYLOC JAM
26 5600005 GAUGE WHEEL, COMPLETE 1 3 X 4 FRAME
27 1150171 PIN, HITCH 2 5/8 X 4-3/4
28 1550169 PIN, HAIR 2 5/32 X 2-15/16
29 1550308 NUT, HEX 1 5/8-11 NC NYLOC JAM
30 1550209 WASHER, FLAT 2 5/8
31 1550091 CAP SCREW, HEX HEAD 1 5/8-11 NC X 5 G5
32 1541625 FITTING, GREASE ZERK 1 1/4-28 NF
PM-10
