BALE RAM GROUP MR802
KEY PART NO. PART NAME QTY. REMARKS
1 1550172 PIN, HITCH 2 5/8 X 6-1/2
2 5802055 SOCKET, RAM EXTENSION 2
3 5802031 RAM EXTENSION 2
4 1550209 WASHER, FLAT 4 5/8
5 5600103 BALE PAN 1
6 1550059 CAP SCREW, HEX HEAD 8 3/8-16 NC X 1-1/4 G5
7 1550129 NUT, HEX 8 3/8-16 NC NYLOC
8 1550145 NUT, HEX 8 1/2-13 NC NYLOC
9 1541159 MOTOR, HYDRAULIC 2 WHITE RE3208040
10 1550009 CAP SCREW, HEX HEAD 8 1/2-13 NC X 1-3/4 G5
11 1550144 NUT, HEX 4 1/2-13 NC NYLOC JAM
12 1550125 NUT, HEX 4 5/8-11 NC
13 2113004 ALL THREAD 2 3/4 NC X 7"
14 5802051 CHAIN HOUSING-RIGHT 1
15 1510077 BEARING, TAKE-UP 2 1-1/4
16 1520245 SPROCKET 4 80BS13 1-1/4 BORE 5/16 KW SS
17 5802054 IDLE SHAFT, BALE RAM 1
18 1550314 BOLT, CARRIAGE 4 1/2 X 4-1/2
19 5802052 CHAIN HOUSING-LEFT 1
20 1550018 CAP SCREW, HEX 10 1/2-13 NC X 1-1/4
21 1550313 NUT, HEX 4 5/8-11 NC NYLOC JAM
22 1520345 CHAIN, ROLLER 2 80 SUPER H X 71"
23 1520076 LINK 2 CONN SUPER 80H
24 5802053 BALE RAM 1
25 1550312 CAP SCREW, HEX HEAD 2 5/8-11 NC X 9
26 1550148 NUT, HEX 2 5/8-11 NC NYLOC
27 1510056 BEARING 4 1-3/4'' CAM FOLLOWER
28 1550316 PIN, ROLL 2 5/16 X 1-3/8
29 5600062 CHAIN CONNECTOR-TOP 2
30 1550349 CAP SCREW, HEX HEAD (NOT SHOWN) 2 5/8-18 NF X 1 G5
31 1550226 WASHER, SPLIT LOCK (NOT SHOWN) 2 5/8
PM-8
