Parts list, Mr802, Frame lift hydraulic group – Ag-Bag MR802 User Manual
Page 14: Pm-16
FRAME LIFT HYDRAULIC GROUP
MR802
KEY PART NO.
PART NAME
QTY
REMARKS
1
1541346
VALVE
1
4 BANK V-20 BI-DWG# 002
2
1540573
FITTING, HYDRAULIC COUPLER
4
C5135 X 8 X 10
3
5802073
HOSE ASSEMBLY
1
42506U-668606-01900
4
5802074
HOSE ASSEMBLY
1
42506U-668606-03800
5
5802075
HOSE ASSEMBLY
2
42506U-606606-01900
6
1540651
FITTING, HYDRAULIC COUPLER
4
C5405 X 6
7
1541085
VALVE, BALL
4
1/4
8
1540456
FITTING, HYDRAULIC COUPLER
4
C3409 X 4
9
1540379
FITTING, HYDRAULIC COUPLER
2
C3069 X 4
10
1540735
FITTING, HYDRAULIC COUPLER
2
C5755 X 6
11
5802084
HOSE ASSEMBLY
1
42506U-668606-01800
12
1540653
FITTING, HYDRAULIC COUPLER
2
C5405 X 6 X 6
13
1540384
FITTING, HYDRAULIC COUPLER
2
C3069 X 8 X 4
14
5802085
HOSE ASSEMBLY
1
42506U-666606-02000
15
5802086
HOSE ASSEMBLY
1
42506U-666606-02100
16
1540516
FITTING, HYDRAULIC COUPLER
6
C5205 X 6 X 8
17
1541109
VALVE, FLOW DIVIDER
2
B100 1/2 PORT
18
5802087
HOSE ASSEMBLY
1
42506U-666606-01500
19
5802081
HOSE ASSEMBLY
1
42506U-666606-04800
20
1540654
FITTING, HYDRAULIC COUPLER
2
C5405 X 6 X 8
21
1541374
CYLINDER, HYDRAULIC
2
DB330
22
1540442
FITTING, HYDRAULIC COUPLER
2
C3309 X 4
23
1540366
FITTING, HYDRAULIC COUPLER
2
9100 X 6 X 4
24
1540590
FITTING, HYDRAULIC COUPLER
8
C5325 X 6
25
1540749
FITTING, HYDRAULIC COUPLER
8
C5924 X 6
26
5802093
HARDLINE ASSEMBLY
1
WHEEL LIFT RETURN-VALVE SIDE
1541068
TUBING, HYDRAULIC
1
1/2''
1540217
FITTING, NUT
2
FC-2875-8
1540224
FITTING, SLEEVE
2
FF-9605-8
27
5802094
HARDLINE ASSEMBLY
1
FRAME LIFT RETURN-VALVE SIDE
1541068
TUBING, HYDRAULIC
1
1/2''
1540217
FITTING, NUT
2
FC-2875-8
1540224
FITTING, SLEEVE
2
FF-9605-8
28
5802091
HARDLINE ASSEMBLY
1
FRAME LIFT PRESSURE-ENGINE SIDE
1541068
TUBING, HYDRAULIC
1
1/2''
1540217
FITTING, NUT
2
FC-2875-8
1540224
FITTING, SLEEVE
2
FF-9605-8
29
5802095
HARDLINE ASSEMBLY
1
WHEEL LIFT PRESSURE-ENGINE SIDE
1541068
TUBING, HYDRAULIC
1
1/2''
1540217
FITTING, NUT
2
FC-2875-8
1540224
FITTING, SLEEVE
2
FF-9605-8
30
5802078
HOSE ASSEMBLY
2
42506U-606606-02000
31
5802088
HOSE ASSEMBLY
1
42506U-606606-03400
32
5802089
HOSE ASSEMBLY
1
42506U-606606-03500
33
1540092
CYLINDER, HYDRAULIC
2
DB208
34
1550156
PIN, CLEVIS
8
1 X 3-1/4
35
1540545
FITTING, HYDRAULIC COUPLER
4
C5305 X 6
36
1550169
PIN, HAIR
8
5/32 X 2-15/16
37
5802090
HOSE ASSEMBLY
1
42506U-668608-04100
38
5802093
HARDLINE ASSEMBLY
1
FRAME LIFT RETURN-ENGINE SIDE
1541068
TUBING, HYDRAULIC
1
1/2''
1540217
FITTING, NUT
2
FC-2875-8
1540224
FITTING, SLEEVE
2
FF-9605-8
PM-16
