AT91SAM9XE-EK Evaluation Board User Guide
2-1
6311A–ATARM–04-Feb-08
Section 2
Setting Up the AT91SAM9XE-EK Board
2.1
Electrostatic Warning
The AT91SAM9XE-EK evaluation board is shipped in protective anti-static packaging. The board must
not be subjected to high electrostatic potentials. A grounding strap or similar protective device should be
worn when handling the board. Avoid touching the component pins or any other metallic element.
2.2
Requirements
In order to set up the AT91SAM9XE-EK evaluation board, the following items are needed:
the AT91SAM9XE-EK evaluation board itself.
AC/DC power adapter (5V at 2A), 2.1 mm by 5.5 mm
2.3
Layout
