- 6 -
English
Features - Getting started
HL 1610 S
The tool is switched ON and OFF at the two-stage switch on the back of the grip handle. Airflow and tem-
perature can be adjusted to 2 settings. Stage 1 reaches 575 °F at an air flow of 8.5 cf/min, stage 2 reaches
950 °F at 14.8 cf/min.
HL 2010 E
The tool is switched ON and OFF at the three-stage switch on the back of the grip handle. In addition to three-
stage speed/airflow control, temperature can be continuously adjusted over a range of 120 °–1150 °F by the
pushbuttons. The target temperature can be increased in 10 °F steps by pressing the ”+” side of the tempera-
ture pushbutton or reduced by pressing the ”–” side of the temperature pushbutton. Pressing the button briefly
increases or reduces the target temperature by one 10 °F step. Keeping the button pressed will continue to
increase or reduce the temperature in steps of 10 °F until the button is released or the minimum or maximum
temperature is set.
Blower stage 1 delivers a temperature of 120 °F. The tool will take a short while to cool to 120 °F after switching
down to blower stage 1 when it has been operating at high temperatures on blower stage 2 or 3. While the
tool is cooling down, the LCD display shows the actual temperature at the nozzle outlet. After switching OFF,
the tool stays in the last setting. The outlet protection tube can be removed in order to install the overhead
security hanger.
HL 1810 S
The tool is switched ON and OFF at the three-stage switch on the back of the grip handle. Airflow and
temperature can be adjusted to 3 settings. Stage 1 is a Cool air stage at 120 °F with an airflow rate of
3.6 cf/min. Stage 2 reaches 750 °F at an airflow of 10.0 cf/min., stage 3 delivers 1100 °F at 15.9 cf/min.
The outlet protection tube can be removed in order to install the overhead security hanger.
HL 1910 E
The tool is switched ON and OFF at the three-stage switch on the back of the grip handle. In addition to three-
stage speed/airflow control (stage 1 is a ”Cool-air stage” at 120 °F ), temperature can be continuously adjusted
over a range of 120 °–1100 °F at the thumbwheel. The numbers (1 to 9) on the thumbwheel serve as a guide
only. Whereas ”1” means 120 °F, the maximum temperature of 1100 °F is attained at ”9”.
Airflow can be adjusted to the three stages of 3.6/10.6/17.6 cf/min. The outlet protection tube can be removed
in order to install the overhead security hanger.
Please note: The distance from the object you are working on depends on material and intended method
of working. Always try out the airflow and temperature on a test piece first! Using the attachable accessory
nozzles (see accessories page on the cover) the flow of heat can be controlled with maximum precision.
Take care when changing hot nozzles! When using the heat gun in the self-resting position, make sure
it is standing on a stable, non-slip and clean surface.
Temperature
Dial Setting
1
2
3
4
5
6
7
8
9
Temperature
Range °F
100 – 160 °F
200 – 300 °F
375 – 475 °F
475 – 575 °F
600 – 700 °F
725 – 825 °F
850– 950 °F
975 – 1075 °F
1025 – 1125 °F
Temperature
Range °C
37.8 – 71.1 °C
93.3 – 148.9 °C
190.6 – 246.1 °C
246.1 – 301.7 °C
315.6 – 371.1 °C
385.0– 440 .6 °C
454.4 – 510.0 °C
523.9 – 579.4 °C
551.7 – 607.2 °C
Sample
Applications
cleaning surfaces
activating adhesives
shaping/removing flooring materials
welding PE, LDPE, PP, thawing pipes
welding ABS, PBT, PC; lap welding plastic sheeting
de-soldering circuit boards
stripping paint, loosening nuts/screws
de-soldering copper pipes
soldering
