- 13 -
English
1 4 12 13
3
8
6
5
9
2
10
7
Spare Parts List HL 2010 E
Part No. Pos.
02820
02420
02621
02629
02723
02523
—
02829
02320
02225
02120
02426
1 + 2
3
4
5
6 + 8
7
9
10
11
12
13
14
HL 2010 E, Type 3482
Housing Set incl. Labels
Switch with Markings (external)
Softgrip
Rubber Soft Stand
Power Cord with Strain Relief
Outlet Protection Tube
Power Cord Connector
Set of 5 Housing Screws
PCB/IC Block with Switch and Controls
Motor/Fan Assembly
Heating Element 1500W/120V
Switch (internal)
white
black
2:1
green
red
red blue
blue
yellow
yellow (fuse)
Wiring Diagram HL 2010 E
11
14
