Self-cooling aluminum
output tube
Mesh guard keeps out
foreign bodies
Remove screws to change
heating element
Sturdy rubber power cord
Slide switch with cool air stage
Plug-in key
Baffle adjusts air and tempera-
ture within range
Ergonomic soft grip handle
Color coded keys each lock in
a specific temperature range
Base includes key storage
area
Fully adjustable quick-lock
stand
Support for resting tool
Device components
1
2
3
4
5
6
7
8
9
11
12
10
Available Accessories (sold separately)
8’’ / 200 mm – Spreader for films, packaging
and drying
Item No. 07725
1 / 4 ’’ / 7 mm – Reduction nozzle for desoldering
Item No. 07695
Large reflector for shrink tubing up to 50 mm dia.
Item No. 07705
Small reflector for shrink tubing up to 20 mm dia.
Item No. 07715
Your dealer has these nozzles available for you as accessories
A
B
C
D
for purchasing a STEINEL heat
tool. This device lets you perform
a wide variety of tasks such as
drying, shrinking, removing var-
nish, etc. safely and reliably. All STEINEL devices are manufac-
tured according to the highest
standards and subjected to
rigorous quality testing. Used in the proper manner, this
heat tool will give you lasting
satisfaction.
