GE 73611 Foreign Voltage Adapter - Manual

OPERATING INSTRUCTIONS
Most appliances sold in the USA and Canada are designed with 2-Flat-Pin
plugs and operate on voltages of 110/120 volts. Foreign country voltage
may be 220/240 or 110/120 volts with variations in the wall outlets. This
Foreign Voltage Adapter is designed to convert your 2-Flat-PIN plug to the
correct type of foreign wall outlet and convert the foreign electricity to
100/120 volts to fit your appliances. Model 73611 Foreign Voltage Adapter
easily switches between electric appliances requiring 50 watt maximum
power (small TVs, video cameras, electric razors, stereos, notebook
computers, etc) and heat producing appliances requiring 50 to 1600 watt
power (blow dryers, travel irons, coffee makers, etc.)
CAUTION:
Before using with any appliance, it is very important to check the wattage
rating of the appliance and set the Wattage switch to the correct wattage of
the appliance being used. If the wattage switch is set to the wrong wattage
setting, your appliance could be damaged.
Please note that some appliances may operate slower when used in
foreign countries because they operate on 50Hz, while USA/CANADA
operate on 60Hz.
Most foreign countries have unstable voltage conditions. These conditions
may shut off your appliances prematurely. This does not mean your
appliance of Foreign Voltage is not working properly.
CAUTION – RISK OF FIRE AND ELECTRIC SHOCK:
Remove adapter from the receptacle when not in use. "It shall then state
"Use only with these outlet types" together with an outline drawing of
the appropriate outlet configurations and identification of the applicable
country(ies) to which the configurations apply. The section shall then
include the following if the ouput is other the 60 Hz: "The output is
[frequency out] Hz and may tend to overheat certain types of products
rated 60 Hz. Closely observe the connected equipment during the first few
uses for indications of overheating. If overheating occurs, discontinue use
immediately and have the product serviced or destroyed. Subsequent use
of a previously overheated product may result in a risk of fire or
electric shock."
Move the Wattage Switch to
the 50 Watt setting for use
with the electric appliances
requiring 50 watt maximum
power (small TVs, Video
cameras, electric razors,
stereos, notebook computer,
etc) Wattage Switch is set
for 1600 Watts for use
with heat producing
appliances requiring
50 to 1600 watt power
(blow dryers, travel
irons, coffee makers,
etc.)
SAFETY PRECAUTIONS
1. Read and follow all safety instructions before operating this product.
2. Heed all warnings on the product and all warnings contained in the
user’s manual.
3. Keep instructions for future reference.
4. Before using with any appliance, check the wattage rating of the
appliance and set the wattage switch to the correct wattage of the
appliance being used. If the wattage switch is set to the wrong wattage
setting, your appliance could be damaged.
5. For indoor use only.
73611 Dual Wattage Foreign Voltage Adapter
IMPORTANT SAFETY INSTRUCTIONS: READ ALL INSTRUCTIONS CAREFULLY BEFORE USAGE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT:
Do not leave Foreign Adapter in wall outlet when not in use. After using,
remove Foreign Voltage Adapter from wall outlet.
Do not use with life support monitoring equipment like respirators, heart
monitors, etc.
HOW TO USE:
1. Check the wattage rating of the appliance and set the wattage switch to
the correct wattage of the appliance being used.
2. Be sure to check the AC voltage and wall outlet style before using your
Foreign Voltage Adapter.
3. Select an Adapter using Adapter Chart below.
4. Plug the Adapter, if needed, onto the Foreign Voltage Adapter.
5. Plug the Foreign Voltage
Adapter into the wall
outlet for use with your
appliance.
6. After following the above
procedures, just plug your
appliance into the Foreign Voltage
Outlet located on the front of the
Foreign Voltage Adapter and it is
easy to use.
7. When finished, remove your Foreign Voltage Adapter, from the wall
outlet.
90 DAY UNLIMITED: Jasco Products Company warrants this product to be free from
manufacturing defects for a period of ninety days from the original date of consumer
purchase. This warranty is limited to the repair or replacement of this product only and
does not extend to consequential or incidental damage to other products that may
used with this unit. This warranty is in lieu of all other warranties express or implied.
Some states do not allow limitations on how long an implied warranty lasts or permit
the exclusion or limitation of incidental or consequential damages, so the above
limitations-may not apply to you. This warranty gives you specific rights, and you may
also have other rights which may vary from state to state. If unit should prove defective
within the warranty period.
Jasco Products Company LLC
10 E. Memorial Rd. Oklahoma City, OK 73114
WARNING
• Do not use with computers, hair straighteners, kitchen
appliances or power tools.
• Do not use with life support monitoring equipment like
respirators, heart monitors, baby monitors, etc.
• Use this unit only with devices with a polarized electrical
plug. Polarized plugs have two blades only with one
blade wider than the other.
Adapter Chart
Adapter Country(s) Adapter Country(s)
No Adapter
Most
European
Countries
Purple ▼
Africa
Asia
Europe
Middle East
Purple
Africa
Asia
Europe
Middle East
Blue ▼
Australia
New
Zealand
Orange ▼
North
America
South
America
Caribbean
Green ▼
Africa
Great
Britain
Hong Kong
