GE ZGU122NPSS - Manual

monogram.com
73
Fr
ee-standing grills
Built
-in grills
Dual-burner cook
top
monogram.com monogram.com
Dual-burner cooktop
Dual-burner cooktop
ZGU122NPSS (natural gas)
Overall dimensions
(WxHxD in inches):
13 x 11 x 26-1/2
Approx. shipping wt. (lbs.)
55
• 15,000-BTU sealed side burners
• Reversible burner grates are contoured
on one side to hold a wok
• Stainless steel cover
Dual-burner cooktop
ZGU122NPSS
7/8" Overlap
at the back
*25" Countertop Depth
28" to Front of Bullnose
26-1/2" to Front
of Control Panel
* The weight of the cooktop is fully supported by the side
trims. The back of the cooktop overlaps the back edge of
the cutout.
26-1/2"
13"
10-1/2" to
the Bottom
of the Side
Support Flange
12" Min. to
Combustibles
on All Sides
11"
10-7/8"
24-1/2"
11-7/8"
Gas and Electrical Locations
Outdoor
Cooktop
ZGU122
General features
A pair of 15,000-BTU sealed side burners offers additional
space for preparing pasta or boiling water.
The burner grates are uniquely contoured on one side to
hold woks.
Stainless steel cooktop burner cover included.
Electronic, 120-volt ignition system makes grill activation as
simple as pressing a knob control.
High-altitude conversion kit WB28X10119 allows the grill to
maintain gas efficiency in mountaintop locations.
The cutout must be
completely covered with
non-combustible material
such as stone, brick, ceramic
tile, concrete board, etc. The
countertop surface and edges
must be flat and level.
If the countertop has an
overhang, it must be notched
or cut back flush with the front
face of the cabinet below.
The cooktop drops into the opening and hangs from the side
flanges. It does not require support from the bottom.
• This gas cooktop cannot be used below any type of
overhead construction.
• Allow 12" minimum clearance on both sides and the back
of the cooktop to adjacent vertical combustible construction.
• This cooktop is designed for outdoor use only.
Do not locate the cooktop in a building, garage or other
enclosed or semi-enclosed area.
