GE ZIP360NZ - Manual (Page 14)

14
STEP 10 INSTALL 1/4” FRAMED PANELS
• There are two sets of holes in the handle side trim.
Replace handle side trim by installing the original screws
in the FRONT screw holes.
• Secure the handle to the door using the REAR
screw holes.
• Follow the same procedures to install the second door
panel and the drawer panel.
IF YOU ARE INSTALLING OVERLAY PANELS,
GO TO STEP 10A.
Install door and drawer panels:
• Open door to 90°. Remove the 4 Phillips head screws
from the door handle.
• Remove handle. Retain all screws.
• Remove 4 screws holding trim, lift off trim.
Retain screws.
• Slide framed panel into the door trim.
Standard supplied handle shown
in 1/4” panel position.
194Dia12
Installation Instructions
