STEP 8 ADJUST DOOR SWING
NOTE: This refrigerator has a 2-position door stop.
When space does not allow the door to swing open
fully to 130°, you may change the door swing to a 90°
opening. Skip this step if door opening is satisfactory
for your installation situation.
• Lift the grille panel to access the wire cover trim.
• Remove screws on both sides of the wire cover trim
and rotate off.
• Use pliers to unscrew door stop and reinstall into the
90° position.
STEP 9 INSTALL GRILLE PANEL
• Raise the grille panel to stop position.
13
• Reinstall the wire cover trim.
729Dia79
194Dia25
• Loose screws on side trim behind frame. Remove
bottom trim.
• Slide panel over the metal backer panel and into
the trim.
• If necessary, tap with a wood block until panel slips
under the top trim piece.
• Reassemble bottom trim. Tighten screws.
• Adjust the hinge spring to accommodate the panel
weight, if necessary.
Installation Instructions
Remove wire cover
trim screws
Raise Grill Panel
Adjust Nut Below Spring to
Accommodate Panel Weight
Loosen
Side
Trim
Screw
Loosen
Side
Trim
Screw
