Aga Ranges LEGACY 36 F104650-01 - Manual (Page 3)

Contents
Servicing Notes 4
1. To Remove the Hand Rail 4
2. To Remove Control Panel 4
3. To Remove the Cooktop 4
4. To Remove a Side Panel 4
5. To Remove Oven Light Switch 5
6. To Remove Electronic Timer 5
7. To Remove a Thermostat 5
8. To Change Broiler Controller 5
9. To Change a Cooktop Tap 5
10. To Change a Cooktop burner orifice 5
11. To Change Cooktop Burner Electrode 5
12. To Remove or Change a Cooktop Burner. 6
13. To Remove Broiler Outer Door Panel 6
14. To Remove Main Oven Door 6
15. To Change Main Oven Door Outer Panel 7
16. To Change Main Oven Door Catch 7
17. To Change Oven Door Seal 7
18. To Adjust Oven Door Catch Keep 7
19. To Change Ignition Generator 8
20. To Remove Oven Inner Back. 8
22. To Replace an Oven Fan 8
23. To Remove an Oven fan Element 8
24. To Remove Broiler Element. 8
25 To Remove the LH Oven Bottom and Top Elements 9
26. To change Main oven light bulb. 9
27 To Remove Tall Oven Door 9
28. To Change Tall Oven Door Outer Panel 9
29. To Change Tall Oven Door Magnetic Latch 9
30. To Replace the Cooling fan 9
Schematic diagram of the Range 10
Technical Data 12
