Installation Preparation
CUTOUTS AND CLEARANCES
• Measure carefully when cutting the countertop.
• Make sure sides of the opening are parallel and
rear and front cuts are exactly perpendicular
ULJKWDQJOHVWRWKHVLGHV
• Measure to be sure there is room for clearances
to the front edge of the countertop.
• Refer to cooktop installation instructions to be sure
WKDWPRGHOV¿WLQWRWKHEDVHFDELQHWVEHLQJXVHG
• Draw lines on the countertop to follow as a cutting
guide.
• Measure and mark cooktop and vent overlaps to be
VXUHWKHUHLVHQRXJKÀDWFRXQWHUWRSGHSWK
‡7KHFDELQHWVLGHZDOOVVKRXOGEHZLWKLQµRIWKH
vent body. The cabinet back wall should be within
µRIWKHYHQWERG\UHIHUWRCreative Solutions
• Measure the base cabinet width at the top and
bottom to ensure it meets the minimum width
requirements .
30" COOKTOP AND DOWNDRAFT
COMBINATION
The cooktop must be installed per manufacturer’s
installation instructions.
IMPORTANT: The countertop cutout depth requires
PLQLPXPÀDWFRXQWHUWRSVXUIDFHDQG
minimum total countertop depth.
NOTE: Before you begin, measure and mark depth
WRHQVXUHWKDWDGHTXDWHÀDWFRXQWHUWRSVXUIDFH
is available.
For cooktop and downdraft combination depth:
• Follow cooktop installation instructions for cooktop
and downdraft combination installation.
‡2WKHUZLVHDGGWRWKHFRRNWRSFXWRXWGHSWK
NOTE:$GGWRWKHFRRNWRSFXWRXWGHSWKIRU
-3DQG-3
*Required to maintain UL or CSA approvals
30"
0LQLPXP
0LQLPXPÀDWFRXQWHU
top behind cutout required
Side View: Installed Vent Front View: Installed Vent
Cooktop Cooktop
4-1/2” Max
5-1/2”
Max
5-1/2”
Max
“A”
Width
“A”
Width
MODEL “A” Minimum Width
PVB98
ZVB36
34”
PVB94
ZVB30
28-1/2”
