GE PVB94STSS - Manual (Page 13)

13
Installation Instructions
4 CONNECT POWER
Plug power cord into properly grounded receptacle.
5 INSTALL FILTERS, CHECK OPERATION
‡3UHVVWKH212))SDGRQWKHFRQWURO
to raise the vent.
‡6OLS¿QJHUVLQWRWKHYHQWKROHV/LIWWKHYHQW
straight up and pull forward.
‡6OLGH¿OWHULQWRWKHUHWDLQHUVDQGFORVHWKHYHQW
• Press the Fan Speed HIGHER pad to start the
blower. Adjust the blower by pressing HIGHER or
LOWER.
• 7RORZHUWKHYHQWSUHVVWKH212))SDG
NOTE: It is not necessary to turn the fan OFF
before lowering the vent. The fan will automatically
turn off when the vent is lowered. When the fan
is not turned off before lowering the vent, it will
automatically come on at the previously set speed
when the vent is fully raised.
IMPORTANT: The vent can be activated by pressing
the pads on the switch. Do not use excessive force
or sharp objects to activate the switch. Damage
could occur and void the warranty.
Filter Tabs
Retainers
