Technical Information
This chapter contains technical information about your LCD Monitor.
Monitor Information
LCD Module 15-in (38.1 cm), active matrix TFT, anti-glare coating, 0.297 mm pixel pitch
Display Size 304.1 mm x 228.1 mm
Viewing Angle
Left/Right
Up/Down
-60° ~ 60°
-55° ~ 45°
Luminance
Contrast Ratio 220 cd/m 2 (Typical)
350 : 1 (Typical)
Display Colors 16.7 Millions
AC Adapter
Input
Output
100 ~ 240 V
AC
Full Range, 50/60 Hz. < 1.2 A @ 110V; < 0.6 A @ 230 V
12 V
DC
, 3.3 A
Power consumption Operating mode: 30W max.
Sleep mode: 2W max.
Signal Input
Video Signal
Sync signals RGB positive 0.7V
PP
, 75 ohm
Separate, TTL Level
Line (horizontal)
frequency
3 0 kHz ~ 63 kHz
Raster (vertical)
frequency
56 Hz ~ 75 Hz
Pixel dot clock 80 MHz (maximum)
Recommended mode 1024 x 768 @ 60 Hz
Pedestal tilt 20° forward, -5°backward
Dimensions
(W x H x D)
341mm x 317.43mm x 140mm
341mm x 338.1 mm x 67.6 mm (pedestal fold)
Net weight
Gross weight
3.0 kg
4.5 kg
