Parts – Amcor NanoMax PORTABLE AIRCONDITIONER User Manual
Page 6
Parts
4
1. Handle
2. Control panel
3. Air outlet
4. Air inlet with filter
5. Exhaust hose with adapter
6. Power cord hanger
7. Exhaust air outlet
8. Water stopper (plug inside)
9. Casters
10. Adjustable Window Slide Bar
11. Flexible Drain Hose
12. Exhaust hose
13. IR Ergonomic Remote Control
14. Exhaust Hose Window
Slide Bar Connector
15. Insulation tape
16. Spiral
water pipe with connector
5
8
7
9
6
4
1
2
3
4
11
10
12
13
16
14
15
