Specifications
General• LCD Panel (17") • Resolution • Preset Display Modes • Physical Characteristics • Environmental •
Power Cord Set Requirements • VGA Connector Pin Assignments • Plug and Play DDC2B Feature
All specifications represent the typical specifications provided by HP’s component manufacturers; actual
performance may vary either higher or lower.
General
Model number w17e / W17q
LCD Panel (17")
Driving system TFT Active Matrix Color LCD
Size 431.8 mm (17" diagonal)
Video R, G, B Analog Interface
Separate sync. H/V TTL & TMDS
Display color 262,000 colors
Dot clock 135 MHz maximum
Pixel Pitch 0.255 mm (H) x 0.255 mm (V)
Face treatment Antiglare polarizer with hard coating
Viewable angle 140° (H), 130° (V)
Resolution
Horizontal scan range 30 kHz to 83 kHz
Horizontal scan size (Maximum) 367.2 mm
Vertical scan range 55 Hz to 75 Hz
Vertical scan size (Maximum) 229.5 mm
Optimal preset resolution 1440 x 900 at 60 Hz
Highest preset resolution 1440 x 900 at 75 Hz
Highest addressable resolution 1440 x 900 at 75 Hz
Plug & Play VESA DDC2B
Input Connectors D-Sub VGA 15-pin and audio jack
Input Video Signal Analog: 0.7Vp-p (standard), 75 OHM
Power Source 100~240V , 47~63 Hz
