HP Pavilion v72 17 inch CRT Monitor - Manual (Page 31)

User’s Guide B–1
B
Technical Specifications
v72 Series Monitor
Screen Size 17” (43 cm) visual diagonal
Viewable screen size 16” (40.6 cm)
Dot Pitch 0.28 mm (Diagonal)
Display Area Default 234 x 312 (mm) typical
Display Colors Infinite
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024 Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
60 Hz (maximum resolution)
Synchronization (Horizontal) 30 to 70 KHz
Synchronization (Vertical) 50 to 140 Hz
Max Pixel Clock 110 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage
Frequency 100 to 240V
50 +3 to 60 +3 Hz
