Technical Specifications
User’s Guide
B–7
Preset Video Modes
The monitor automatically recognizes many preset video input modes that will appear properly sized and centered
on the screen. The following modes are assigned at the factory and are the most commonly used display resolutions:
■ vp15 supports preset modes 1 through 11
■ vp17, vp19, and FP1707 support preset modes 1 through 15
■ w1707 supports preset modes 1 through 15
Factory Preset Video Input Modes, vp15, vp17, vp19, and FP1707
Preset
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1
640 x 480
31.4
59.9
2
640 x 480
37.8
72.8
3
640 x 480
37.5
75.0
4
720 x 400
31.4
70.0
5
800 x 600
37.8
60.3
6
800 x 600
48.0
72.1
7
800 x 600
46.8
75.0
8
832 x 624
49.7
74.5
9
1024 x 768
48.3
60.0
10
1024 x 768
56.4
70.0
11
1024 x 768
60.0
75.0
12
1152 x 870
68.6
75.0
13
1152 x 900
71.7
76.1
14
1280 x 1024
63.9
60.2
15
1280 x 1024
79.9
75.0
Factory Preset Video Input Modes, w1707
Preset
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1
640 x 480
31.4
59.9
2
640 x 480
37.8
72.8
3
720 x 400
31.4
70.0
4
800 x 600
37.8
60.3
5
800 x 600
46.8
75.0
6
832 x 624
49.7
74.5
7
1024 x 768
48.3
60.0
8
1024 x 768
60.0
75.0
9
1152 x 870
68.6
75.0
10
1152 x 900
61.8
65.9
