Front Panel Controls
Figure 2-4 Monitor front panel controls
Table 2-2 Monitor front panel controls
Control Function
1 Power LED Blue = Fully powered.
Amber = Sleep mode.
Off = Off mode.
2 Power Turns the monitor on or off.
3 Menu Opens, selects or exits the OSD menu.
4 Minus Moves the OSD cursor down/decreases the OSD adjustment
level.
5 Plus Moves the OSD cursor up/increases the OSD adjustment
level.
6 OK If the OSD menu is on, press to select the highlighted menu
item.
NOTE: To view an OSD menu simulator, visit the HP Customer Self-Repair Services Media Library at
http://www.hp.com/go/sml .
Front Panel Controls 5
