HP Z Display Z27i 27-inch IPS LED Backlit Monitor - Manual (Page 11)

Z27i and Z30i Models
Component Function
1 USB 3.0 Downstream
Connectors (side panel) Connects optional USB devices to the monitor.
2 Master Power Switch Turns off all power to the monitor.
NOTE: Putting the switch in the Off position will yield the
lowest power state for the monitor when not in use.
3 AC Power Connector Connects the AC power cord to the monitor.
4 DisplayPort Connects the DisplayPort cable to the monitor.
5 VGA Connects the VGA cable to the monitor.
6 DVI-D Connects the DVI-D cable to the monitor.
7 HDMI Connects an HDMI cable to the monitor.
8 Audio Out Connects headphones or optional HP Speaker Bar to the
monitor.
9 USB 3.0 Upstream
Connector Connects the USB hub cable to the monitor's USB hub
connector and to a host USB port/hub.
10 USB 3.0 Downstream
Connectors Connects optional USB devices to the monitor.
Rear Components 5
