B Technical Specifications
NOTE: All performance specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component manufacturers' typical level
specifications for performance and actual performance may vary either higher or lower.
Table B-1 HP 15.6” LCD Monitors
Display
Type
39.5 cm
TFT LCD
15.6 inches
Viewable Image Size 39.5 cm diagonal 15.6-inch diagonal
Tilt -5 to 20°
Maximum Weight
Monitor only
With packaging
2.7 kg
3.7 kg
5.9 lbs
8.15 lbs
Dimensions
Height (with base)
Depth
Width
304.7 mm
190 mm
376.3 mm
11.99 inches
7.48 inches
14.81 inches
Maximum Preset Resolution 1366 x 768 (60 Hz)
Optimal Preset Resolution 1366 x 768 (60 Hz)
Pixel Clock 140 MHz
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin
Input Video Signal Analog: 0.7Vp-p (standard), 75 OHM, Positive
Connector Type 15-pin Mini D-Sub
Signal Cable Type Detachable
Horizontal scan range 24 kHz - 83 kHz
Horizontal scan Size (Maximum) 344.232 mm
Vertical scan range 50 Hz - 73 Hz
Vertical scan Size (Maximum) 193.536 mm
Speakers (Select Models) 2 x 1W
