HP LV1561ws 15.6-inch Widescreen LCD Monitor - Manual (Page 20)

Icon Main Menu Submenu Description
Custom Settings saved when user adjusts the Brightness, Contrast, or
Color in one of the QuickView options.
Language Selects the language in which the OSD menu is displayed.
Management Selects the power-management features of the monitor.
Volume Adjusts the volume level.
OSD Control Adjusts the position of the OSD menu screen to:
● Horizontal OSD Position-Changes the viewing position of
the OSD menu to the left or right area of the screen. The
factory default range is 50.
● Vertical OSD Position-Changes the viewing position of the
OSD menu to the top or bottom area of the screen. The
factory default range is 50.
● OSD Transparency-Adjust to view the background
information through the OSD
● OSD Timeout-Sets the time duration in seconds that the
OSD is visible after the last button is pressed. The factory
default is 30 seconds.
Power Saver Enables the power saving feature (see Energy Saver Feature
on page 20 ). Select:
● On
● Off
Mode Display Displays the resolution, refresh rate and frequency information
on the screen each time the OSD Main Menu is accessed.
Select:
● On
● Off
Power-On Status Display Displays the operating status of the monitor each time the
monitor is powered on. Select the location to display the status
to:
● Top
● Middle
● Bottom
● Off
DDC/CI Support Allows the computer to control some OSD menu features such
as brightness, contrast and color temperature. Set to:
● On
● Off
Bezel Power LED Turns the light (LED) in the power button On and Off. When set
to Off, the light will remain off at all times.
Table 4-2 OSD Menu (continued)
14 Chapter 4 Operating the Monitor ENWW
