HP ProDisplay P19A 19-inch LED Backlit Monitor - Manual (Page 17)

4 Technical Specifications
NOTE: All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary.
Table 4-1 P19A Specifications
Maximum Weight (Unpacked) 3.47 kg 7.65 lbs
Dimensions (include stand)
Height
Depth
Width
41.82 cm
20.64 cm
41.40 cm
16.46 inches
8.13 inches
16.3 inches
Maximum Graphic Resolution 1280 x 1024 (60Hz) analog input
Optimum Graphic Resolution 1280 x 1024 (60 Hz) analog input
Power Source 100 – 240 VAC 50/60 Hz
Input Terminal One VGA connector
Tilt –5° to 25°
Operating Temperature 5° to 35° C 41° to 95° F
Operating Altitude 0 to 5,000 m 0 to 16,400 ft.
NOTE: For more information, go to http://www.hp.com/go/productbulletin and search for your specific display model to find
the model-specific QuickSpecs.
Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory
defaults. This monitor automatically recognizes these preset modes and they will appear properly
sized and centered on the screen
Table 4-2 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 Ч 480 31.47 59.94
2 720 Ч 400 31.47 70.09
3 800 Ч 600 37.88 60.32
4 1024 Ч 768 48.36 60.00
5 1280 Ч 960 60.00 60.00
6 1280 Ч 1024 63.98 60.02
Preset Display Resolutions 11
