B Technical Specifications
NOTE: All performance specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component manufacturers' typical level
specifications for performance and actual performance may vary either higher or lower.
HP LP2275w Model
Table B-1 HP LP2275w Specifications
Display
Type
55.9 cm wide screen
TFT LCD
22 inches wide screen
Viewable Image Size 55.9 cm diagonal 22–inch diagonal
Tilt Adjustment -5 to 30°
Swivel Adjustment -45 to 45°
Height Adjustment 100 mm range 3.94–inch range
Pivot Clockwise
Maximum Weight (Unpacked) 8.12 kg 17.9 lbs.
Dimensions (include base)
Height (maximum)
Depth
Width
47.8 cm
25.3 cm
50.6 cm
18.8 inches
10.0 inches
19.9 inches
Maximum Graphic Resolution 1680 x 1050 (60 Hz) analog input
1680 x 1050 (60 Hz) digital input
Optimum Graphic Resolution 1680 x 1050 (60Hz) analog input
1680 x 1050 (60Hz) digital input
Text Mode 720 × 400
Dot Pitch 0.282 (H) × 0.282 (W) mm
Horizontal Frequency 30 to 93 kHz
Vertical Refresh Rate 48 to 85 Hz
Environmental Requirements Temperature
Operating Temperature 5 to 35° C 41 to 95° F
38 Appendix B Technical Specifications
Storage Temperature -20 to 60° C -4 to 140° F
