HP LP2475w Model
Table 4-2 HP LP2475w Monitor Front Panel Controls
Control Function
1 Input / Scan Scans all video inputs for valid signals.
2 Input / Quick Select Displays valid video input signals for quick selection.
3 Menu Opens, selects or exits the OSD menu.
4 – (Minus)/Auto ● Navigates backward through the OSD menu and decreases
adjustment levels.
● When the OSD menu is inactive, activates the auto adjustment
feature to optimize the screen image.
5 + (Plus)/Reset ● Navigates forward through the OSD menu and increases adjustment
levels.
● When the OSD menu is inactive, resets the monitor settings to factory
default settings.
6 PIP/POP Turns Picture-In-Picture or Picture-Outside-Picture on or off.
NOTE: The PIP/POP feature must be initially set up using the OSD
menu. Select Video Input Control from the OSD menu to make your PIP/
POP, input source, window size and screen position selections.
7 Power LED Fully powered = Green.
Sleep mode = Amber.
Sleep Timer mode = Flashing Amber.
8 Power Turns the monitor on or off.
