Rear Components
Monitor rear components vary by model.
HP LP2275w Model
Figure 3-2 Rear Components
Table 3-1 HP LP2275w Rear Components
Component Function
1 Cable Lock Provision Provides slot for use with cable security locks.
2 Master Power Switch Turns off all power to the monitor.
3 AC Power Connector Connects the AC power cord to the monitor.
4 DisplayPort Connector Connects the DisplayPort signal cable to the monitor.
5 DVI-I Connector Connects the DVI to VGA signal cable or DVI to DVI-D signal
cable to the monitor.
6 USB Upstream Connector Connects the monitor USB hub cable to a host USB port/hub.
7 USB Downstream Connectors Connects optional USB devices to the monitor.
8 USB Downstream Connectors
(side panel) Connects optional USB devices to the monitor.
Rear Components 7
