Rear Components

Component

Function

1

AC Power Connector

Connects the AC power cord to the monitor

2

DisplayPort

Connects the DisplayPort cable to the monitor (select
regions only)

3

DVI-D

Connects the DVI-D cable to the monitor

4

VGA

Connects the VGA cable to the monitor

5

USB Upstream
Connector

Connects the USB hub cable to the monitor's USB hub
connector and to a host USB port/hub

6

USB Downstream
Connectors (2)

Connects optional USB devices to the monitor

4

Chapter 2 Setting Up the Monitor
