Setting Up the Monitor
Component Function
6 USB Downstream
Connectors Connects optional USB devices to the monitor.
7 USB Downstream
Connectors (side
panel) Connects optional USB devices to the monitor.
Selecting the Signal Connectors and
Cables
The monitor features two DVI-I connectors capable of supporting
either analog or digital input.
The video mode supported by the DVI-I connector is determined
by the video cable used.
■ For digital operation, use the DVI-D signal cable provided.
Connect the DVI-D signal cable to a DVI-I connector on the
monitor and the other end to the DVI connector on the
computer.
■ For analog operation, use the DVI-I to VGA signal cable
provided. Connect the DVI-I to VGA signal cable to a DVI-I
connector on the monitor and the other end to the VGA
connector on the computer.
The monitor will automatically determine which inputs have
valid video signals. The inputs can be selected through the
On-Screen Display (OSD) feature by pressing the Input Select
button on the front panel.
3–4 User Guide
