Aquacal HP7 - Manual (Page 9)

9
5. Changing The Pool Temperature Set Point:
A. Using the Pool / Spa key, select the POOL temperature set point. The pool set point
indicator light will confirm your selection by lighting.
B. The pool temperature set point range is adjustable from 60
°F. to 95° F (104 °
F in latest
models). using the Up
⇑ or Down ⇓ arrow keys. The desired temperature can be selected
by briefly depressing the arrow keys, or by holding them down to scroll the temperature
up or down.
6. Changing The Spa Temperature Set Point:
A. Using the Pool / Spa key, select the SPA temperature set point. The spa set point
indicator light will confirm your selection by lighting.
B. The spa temperature set point range is adjustable from 60
°F to 104°F by using the Up ⇑
or Down
⇓ arrow keys. The desired temperature can be selected by briefly depressing
the arrow keys, or by holding them down to scroll the temperature up or down.
7. Selecting Between
°F And °C:
A. Depress both the Up
⇑ and Down ⇓ arrow keys simultaneously until [CF1] (Celsius /
Fahrenheit) code appears.
B. With the [CF1] code displayed, pressing either the Up
⇑ or Down ⇓ arrow key will
display either a (1) or (0). Select (1) for Fahrenheit temperature display or (0) for Celsius
temperature display. Once the desired temperature display has been selected, not
depressing any buttons for 15 seconds will allow the control to save the selection and
return to the normal operating mode. Pressing the Pool / Spa key will also save the
selection and step to the next menu parameter [ULC] (User Lock Code).
8. User Lock Code Option [ULC] :
This Option Explained:
Heat pumps are shipped from the factory with the ULC option disabled. Enabling the ULC
function permits the heat pump owner to restrict access to the unit controls. With the ULC
option enabled, unless the correct ULC lock code number is entered, changes to Level-1
programming are not possible (I.e.: Altering temperature set points, Pool/Spa selection, C/F
display changes, etc., will not be possible). The ULC option can be thought of as an
electronic lockable cover for the controls.
A. Selecting ULC Option:
1) Depress either of the Up
⇑ or Down ⇓ arrow keys; if [000] is displayed, the ULC
feature is already enabled. If [000] displays, proceed to number “6)” of this section;
otherwise, see number “2” below;
2) Depress both the Up
⇑ and Down ⇓ arrow keys simultaneously until the [CF1]
display appears;
3) Depress the pool/spa key once, the [ULC] display will appear;
4) With [ULC] displayed, pressing either the Up or Down arrow key will display either
“1” or “0”. Selecting “0” will allow the control keypad to remain unlocked. Selecting
“1” will enable the User Lock Code option. Then, to enter a lock code number, press
the pool/spa key once. [ELC] (Enter Lock Code) will display;
