12 A P E X D I G I T A L 13 A P E X D I G I T A L MD - 100 MD - 100
Remote Control
1 2
Open the cover. Insert batteries (AA size).
Make sure to match the + and - on
the batteries to the marks inside the
battery compartment.
PREPARING THE REMOTE CONTROL
Insert the batteries into the remote control so you can use it to operate
the DVD video player.
NOTICE
Follow instructions below because incorrect use of batteries might cause
them to leak or corrode.
• Do not place the batteries in the wrong direction.
• It is dangerous to charge/heat/open or short-circuit the batteries.
• Do not leave dead batteries or mix old/new batteries in the remote control.
• When not using the remote control for a long duration of time, remove the
batteries.
• When difficulties occur, with the remote control, or if the operating range
becomes reduced, then replace the batteries.
• If leakage from the battery occurs, wipe the battery liquid from the battery
compartment, then replace the batteries.
3
Close the cover.
OPERATING WITH THE REMOTE CONTROL
Operating DVD video player with the remote control.
OPERATING DVD VIDEO PLAYER WITH THE EXTENDED
REMOTE SENSOR
ON OFF
L-AUDIO IN-R VIDEO IN
MD-100 O/C
STOP
SKIP
PLAY
MENU
SKIP
DVD/VIDEO CD/ CD PLAYER
30 30
O/C MUTE DISPLAY SWITCH AUDIO SUB-T ANGLE TITLE
1 2 3 4 5 6 7 8
9 0 10+ GOTO STOP STEP/PAUSE
PREV PLAY/ENTER NEXT MENU VOL SLOW
SETUP ZOOM REPEAT A-B REP
1
The remote control must be pointed at the
remote sensor, in order for the DVD player to
function correctly.
Distance: Maximum of 7 m from the front of the
remote sensor.
Angle: Approximately 30˚ from each direction.
*Please do not place the remote sensor towards
any strong light source such as direct sunlight or
illumination.
Plug the jack (male) of the extended remote sensor into the jack
(female) of the real panel of the DVD video player. The extended
remote sensor should be placed on dash board or central console.
O/C MUTE DISPLAY SWITCH
AUDIO SUB-T ANGLE TITLE
1 2 3 4
5 6 7 8
9 0 10+ GOTO
STOP STEP/PAUSE
PREV PLAY/ENTER NEXT
MENU VOL SLOW
SETUP ZOOM REPEAT
A-B REP
Remote Control
NOTICE
• The remote control should be aimed directly towards the remote sensor of
the DVD video player.
• Avoid dropping the remote control.
• The extended remote sensor is usually used in the car.
