2 User’s Guide
Filename: sa517093.doc Title: User’s Guide
Template: Print_2004.dot Author: WASSER Studios Last Saved By: billm
Revision #: 36 Page: 2 of 20 Printed: 12/01/04 12:35 PM
Power Saving
The monitor will be driven into “Power Saving” mode
by the control signal from the display controller, as
indicated by the amber-color power LED.
State Power Consumption LED Light
ON Normal Green
OFF < 4 W Amber
The power saving states will be kept until a control
signal has been detected, or the keyboard or mouse is
activated. The recovery time from Active OFF state back
to ON state is around 10 seconds.
Install the Monitor
• To connect the tilt/swivel base to the monitor, align
hooks with the sockets on bottom side of the monitor,
and gently push the base towards the front of the
monitor.
•
The 15-pin D-shell signal connector on the signal
cable will connect easily to the video adapter output
on your personal computer. Lock both screws on the
connector to ensure a firm connection.
•
Turn the PC power switch ON. Then turn the monitor
power switch ON by pressing the switch inward. The
green power indicator will light up.
•
Allow about 30 seconds for the CRT tube to warm
up. Data will be displayed on the screen.
•
If your display fails to function properly, please first
refer to the section “Troubleshooting” in this manual.
