Using the Rapid Deployment Pack 10
6. Select View>Show Physical Devices.
NOTE: The Physical Devices view is an additional view available only for BladeSystem servers
in the Computers pane. A job can be executed on a server listed in this view.
Table 1 lists the server icons displayed in the Physical Devices view of the Deployment Server
Console.
Table 1 Server icons
Icon Description
Indicates a grouping of physical devices
Indicates a rack
Indicates an enclosure
Indicates a single server blade in a bay
Indicates an unconfigured server blade in a waiting state designated by the user
Indicates a virtual bay
