Layout – Asus PCI-L3C920 User Manual
Page 5
ASUS PCI-L3C920 User’s Guide
5
Layout
NOTE: The Boot ROM chip is an optional item. If your card did not come
with this chip, an empty socket is provided in case you wish to install a Boot
ROM at a later time.
LINK
PCI-L3C920
R
3Com
3C920
Ethernet
Controller
ACT
RJ-45 LAN Port
LAN Controller
Boot ROM
(optional)
PCI Interface
