DISTRIBUTION AMPLIFIERS
3
•
Any changes or modifications to the unit not
expressly approved by Altinex, Inc. could void
the user’s authority to operate the equipment.
ABOUT YOUR DISTRIBUTION AMPLIFIER 2
The DA1406WM is a 1-in 6-out MAC distribution
amplifier designed to connect a single computer
video source to as many as six scan rate
compatible displays. The DA1406WM will pass an
analog video signal up to 1.5 V p-p. Using AGC
sync circuitry, the DA1406WM converts incoming
TTL sync levels to a standard 4V p-p level.
All input and output connectors are 15-pin D
female. This provides superior durability, as the
pins on male connectors can be easily bent
disabling the entire unit. A male to male MAC cable
will typically be required for connection between the
computer and the input to the DA1406WM.
Four ID bit switches allow a user to boot up a
computer at a variety of monitor settings. Though
primarily designed for use with displays using
15-pin D (MAC-type) connectors, the DA1406WM
can pass RGBHV, RGBS, and RGsB format
signals. Adapter cables may be necessary to
accomplish the appropriate connector change.
The DA1406WM is great for desktop use, but can
also be rack-mounted using optional hardware.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION DA1406WM
GENERAL
Input
1
Input Connector 15-pin D Female
Output 6
Output Connectors Six 15-pin D Female
Compatibility MAC, Power MAC,
MAC Quadra, high
resolution RGBHV,
RGBS, RGsB and
RsGsBs
Table 1. DA1406WM General
MECHANICAL DA1406WM
Material 0.1” Al
Finish Gray
Top Panel Lexan
Height (inches) 1.75in (44mm)
Width (inches) 8.50in (216mm)
Depth (inches) 4.50in (114mm)
Weight (pounds) 2.0lbs (0.91kg)
Ship Weight (pounds) 3.2lbs (1.45kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs
Table 2. DA1406WM Mechanical
ELECTRICAL DA1406WM
Input Video Signal
Analog Signal
1.5V p-p max
Impedance 75 Ohms
Input Sync Signal
Horizontal, Vertical, & C-Sync
TTL(+/-)
Sync on Green -0.3V
Impedance 10 k Ohms
Output Video Signals
Analog Signal
Gain of 1.05 (+/-5%)
Fall/Rise Time (ns) 1.4
Impedance 75 Ohms
Output Sync Signal
Composite Sync
TTL(+/-)
Sync on Green -0.3V
Impedance 22 Ohms
Frequency Compatibility
Typical Video Bandwidth
380 MHz
Minimum Video Bandwidth 350 MHz
Horizontal 15-200 kHz
Vertical 47-180 Hz
Coupling DC
Cross-talk -40dB @ 10 MHz
Power
Internal Power Adapter
90-140/200-240 V
Power Consumption 10 watts max.
Table 3. DA1406WM Electrical
