22
IIN1222 / IN1422 / IN1510 / IN1710 OPERATIONS MANUAL - REV. 2 12/04/99 ©1994 - INLINE, INC.
GENERAL SPECIFICATIONS
IN1222 / IN1510 IN1422 / IN1710
Video Connectors
Inputs 1, 2 & 3 - S-Video / Composite Video
(3) 4-Pin Mini DIN
Female
(3) 4-Pin Mini Din
(3) BNC Female
Input 4 - Passive RGB
15-Pin HD Female 15-Pin HD Female
(5) Female BNC
RGB Output
15-Pin HD Female 15-Pin HD Female
(5) Female BNC
Audio Connectors
Inputs 1 - 4 - Stereo Audio
(4) 3.5mm Mini Female
Stereo (Ring/Tip/Sleeve)
(4) Stereo Pairs RCA
Female
Output - Stereo Audio
(1) 3.5mm Mini Female
Stereo (Ring/Tip/Sleeve)
(1) Stereo Pair RCA
Female
Remote Control Connector 9-Pin D Male
Power Supply
Input port IEC Standard Male Connector
Input voltage / frequency 96V - 260 VAC / 40 Hz - 90 Hz
Power consumption 10W
Fuse (1) .5A / 250V Slow Blow
Environmental Capabilities
Operating temperature +5
°
C - +40
°
C
Storage & transport temperature −
20
°
C - +60
°
C
Operating relative humidity 20 - 90%
Storage & transport relative humidity 5 - 95%
Heat radiation direct sunlight radiation not allowed
Operating vibration 10-50Hz @ 2G
Operating position any position
Safety and EMI Data
Safety regulation UL applying
EMI regulation complies with FCC Class A
Dimensions 1.75" H x 8.5" W
x 10.25" D
1.75" H x 19" W
x 11.5" D
Shipping Weight 7.5 pounds 14 pounds
ACCESSORIES INCLUDED
IN1222 / IN1510 IN1422 / IN1710
( 1) - IN1222 Scan Doubler or IN1510 Decoder
(1) - IN9045 15-Pin HD Male to 5-BNC Male, 12’ long
(5) - IN9090 3.5mm Mini Male to 2-RCA Female
(3) - IN9091 4-Pin Mini DIN (S-Video) to RCA Female
(1) - IN9038 15-Pin HD Male to Male Gender Changer
(1) - Power Cord (U.S. Domestic units only)
(1) - Operations Manual
(1) - IN1422 Scan Doubler or IN1710 Decoder
(1) - IN9123 Rack Mounting Kit
(1) - Power Cord (U.S. Domestic units only)
(1) - Operations Manual
