26
 ANTI-TIP BRACKET INSALLATION
To reduce the risk of tipping the range by abnormal usage or improper door loading, the range must
be secured by properly installing the anti-tip device packed with the appliance.
• Place the anti-tip bracket on the floor as shown figure. Anti-tip bracket can be installed on either
right or left side.
• Make the locations of 2 holes of ant-tip bracket on the floor.
• Use a 5/16” masonry drill bit and insert plastic anchor.
• Secure bracket to floor using screws supplied.
• Slide appliance into position.
NOTE: If range is relocated, the bracket must be removed and installed in new location.
1.30"
5.
69
"
1.
18
"
The contour line of back panel of appliance
Install the anti-tip bracket either right or left side.
Anti-tip
Bracket
T
he
c
on
to
ur
l
in
e
of
l
ef
t
pa
ne
l
of
a
pplianc
e
T
he
c
on
to
ur
l
in
e
of
r
ig
ht
p
an
el
o
f
ap
plianc
e
The contour line of front panel of appliance
Move the appliance to the final position.
Anti-tip Bracket
