5
Features
The 4(8)-port 10/100/1000Mbps Gigabit Ethernet Switch was
designed for easy installation and high performance in an environment
where traffic on the network and the number of users increase
continuously.
Switch features include:
Ports
♦ 4(8) 10/100/1000Mbps Gigabit Ethernet port
Performance features
♦
Auto MDI/MDI-X for each port
♦
Support Full/Half duplex transfer mode for 10 and 100Mbps
♦
Support Full duplex transfer mode for 1000Mbps
♦
Wire speed reception and transmission
♦
Store-and-Forward switching method
♦
Supports 8K absolute MAC addresses
♦
Supports 256K Bytes RAM for data buffering
♦
Extensive front-panel diagnostic LEDs
♦
IEEE 802.3x flow control for full-duplex
♦
Back pressure flow control for half-duplex
♦
Optional Rack-mount Kit for 19” standard rack
