Aruba AP 60/61
25
Installation Guide
AP Deployment
Chapter 3
Free-Standing Placement
To place the Aruba AP 60/61 indoors on a flat table or shelf:
Flip open the stand located on the back of the Aruba AP 60/61:
F
IGURE
3-2
Aruba AP 60/61Fold-Out Stand
Place the device on a sturdy table or shelf.
Orient the antennas.
For best performance, swivel the individual antennas (Aruba 60) or antenna array
(Aruba AP61) so that they are oriented vertically. Once mounting is complete,
connect the required cables (see instructions on
C
AUTION
:
Do not place the Aruba AP 60/61 in any place where it
could fall on people or equipment. For more secure
installation, use one of the optional mounting kits.
