Alto-Shaam ITM2-72 - Manual (Page 2)

W E I G H T
ITM2-72/STD ITM2-72/DLX
NET 355 lb (161 kg) EST . 375 lb (170 kg)
SHIP 590 lb (268 kg)
EST
. 610 lb (277 kg)
CRATE D I M E N S I O N S
:
( H X W X D )
68 "
X 38 "
X 84 "
( 1727mm x 965mm x 2134mm)
E L E C T R I C A L
VOLTAGE PHASE CYCLE / HZ AMPS kW CORD & PLUG
120 1 50/60 16.0 1.90 NEMA 5-20P
20A - 125V Plug
230 1 50 7.8 1.80
CORD INCLUDED
NO PLUG
ITM2-72
ISLAND TAKEOUT MERCHANDISER
60-1/2" (153
6mm)
73-1/16" (1855mm)
36-3/4" (933mm)
6-1/2" (165mm)
ELEC. CORD
DROP OUT
66-3/4" (1695mm)
19-15/16" (505mm)
HEATED PLATE AREA
26-1/8" (663mm)
31-3/16" (792mm)
14-1
/2"
(367mm)
26-1/16" (662mm)
91" (2311mm)
13-1/16" (331mm)
TO ELEC. CORD
60-1/2" (1536mm)
73-1/16" (1855mm)
36-3/4" (933mm)
6-1/2" (165mm)
ELEC. CORD
DROP OUT
66-3/4" (1695mm) 19-15/16" (505mm)
HEATED PLATE AREA
26-1/8" (663mm)
31-3/16" (792mm)
14-1
/2"
(367mm)
26-1/16" (662mm)
91" (2311mm)
13-1/16" (331mm)
TO ELEC. CORD
60-1/2"
(1536mm)
72" (1829mm)
36-3/4"
(933mm)
6-1/2" (165mm)
ELEC. CORD
DROP OUT
14-1/2" (367mm)
26-1/8" (663mm)
26-1/16" (662mm)
28-5/16" (719mm)
13-1/16" (331mm)
TO ELEC. CORD
66-3/4" (1695mm) 19-15/16" (505mm)
HEATED PLATE AREA
14-1/2" (367mm)
26-1/16" (662mm)
28" (711mm)
14" (356mm)
TO ELEC. CORD
30-13/16" (782mm)
7-1/8"
(180mm
)
4-1/8" (104mm)
TO ELEC. CORD
72" (1829mm)
60-1/2"
(1536mm)
72" (1829mm)
36-3/4"
(933mm)
6-1/2" (165mm)
ELEC. CORD
DROP OUT
14-1/2" (367mm)
26-1/8" (663mm)
26-1/16" (662mm)
28-5/16" (719mm)
13-1/16" (331mm)
TO ELEC. CORD
66-3/4" (1695mm)
19-15/16" (505mm)
HEATED PLATE AREA
14-1/2" (367mm)
26-1/16" (662mm)
28" (711mm)
14" (356mm)
TO ELEC. CORD
30-13/16" (782mm)
7-1/8"
(180mm
)
4-1/8" (104mm)
TO ELEC. CORD
72" (1829mm)
D I M E N S I O N S :
H x W x D
STANDARD
:
60-1/2" x 72" x 28-5/16" (1536mm x 1829mm x 719mm)
DELUXE
:
60-1/2" x 91" x 31-3/16" (1536mm x 2311mm x 792mm)
HEATED SURFACE DIMENSIONS
: (L x W)
66-3/4" x 19-15/16" (1695mm x 505mm)
ITM2-72/STD ITM2-72/DLX
I N S TA L L AT I O N R E Q U I R E M E N T S
Unit must be installed level, and must not
be installed in any area where it may be
affected by steam, grease, dripping water,
high temperatures, or any other severely
adverse conditions.
C L E A R A N C E R E Q U I R E M E N T S
NO CLEARANCE REQUIRED
H E AT E D P R O D U C T C A PA C I T Y *
63 lb (29 kg) MAXIMUM
Twenty-one (21) chicken boats with dome cover
DOME PACKAGE SIZE : APPROX . 7 "
X 10 " (178mm x 254mm)
* FOR USE WITH PRE - PACKAGED ITEMS ONLY
#80B - 12/08
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE : 262.251.3800 800.558.8744 U . S . A ./ CANADA FAX : 262.251.7067 800.329.8744 U . S . A . ONLY
www.alto-shaam.com
D U E TO O N G O I N G P R O D U C T I M P R O V E M E N T , S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E . P R I N T E D I N U . S . A .
