3) Connect the iPod™ to the Ai-NET compatible Audio Visual Head Unit and

Audio Processor

• While connected to the adapter, the iPod is charged as long as the vehicle’s ignition key is turned to ACC or ON.
• “OK to disconnect” is shown in the iPod’s display while it is connected to the adapter.
• For details, refer to the Owner’s Manual of the connected devices.

Ai-NET

EQ/DIV

NORM

Audio Visual
Head Unit (Ai-NET)
(Sold separately)

iPod, iPod mini
(Sold separately)

To Dock
connector

Fiber optic cable

Ai-NET cable

iPod connection
cable (Included)

To Ai-NET
connector

To Fiber digital
Output terminal

To Ai-NET input
connector

Ai-NET cable
(Included)

Audio Processor
(AI-NET)

(Fiber Digital
compatible)

(Sold separately)

To Fiber digital
Input terminal
(for head unit)

To iPod
terminal

To Ai-NET
connector

To Ai-NET Input
connector
(CHANGER)
