Page 7
DOOR LOCK OUTPUTS
( + ) Lock Pulse
( - ) Unlock Pulse
( - ) Lock Pulse
( + ) Unlock Pulse
GREEN
RED
RED
LT. BLUE
SHOCK SENSOR
Red, Black, Blue,
and Green Wires
BLACK
GREY
APS 400
CONTROL MODULE
GREEN WIRE LOOP
Cut to Eliminate Voltage
Sensing
GRAY WIRE LOOP
Cut for Valet Switch
Override Operation
Page 7
DASH L.E.D.
VALET
SWITCH
