Aps 400, Módulo de control – Audiovox Prestige Platinum 128-4634D User Manual
Page 23
ROJO
AZUL CLARO
NEGRO
GRAY
APS 400
MÓDULO DE CONTROL
LAZO DE CABLE VERDE
Cortar Para Eliminar
Deteccion De Voltaje
Page 23
L.E.D.
INTERRUPTOR DERVANTE
DE EMERGENCIA
VERDE
ROJO
SENSOR DE IMPACTOS
Cables Rojos, Negros,
Azules, y Verdes
SALIDAS DE CERRADURA
DE PUERTAS
(+) Impulso De Cerradura
(-) Impulso De Apertura De Puertas
(-) Impulso De Cerradura
(+) Impulso De Apertura De Puertas
CIRCUITO CABLE GRIS
Corte para el interruptor valet
anulación de operación
